UpKeep Vibration Sensor

Tracking vibration for all of your tools

Make your tools last longer, keep them strong, and clean.

Payments. Software. Hardware. All by UpKeep.

Ranging from temperature to vibration sensors and everything in between, these secure, battery powered, wireless sensors work right out of the box.

Built for premium tracking

Ranging from temperature to vibration sensors and everything in between, these secure, battery-powered.

  • Monitor the vibration patterns of critical assets in real-time from anywhere.
  • Identify potential breakdowns before they happen
  • Identify underperforming assets

How they work

Vibration sensors measure vibration speed and frequency in “3D” (across all dimensions)

  • Vibration measurements are taken every minute and then averaged and transmitted as often as once every 10 minutes.
  • Alerts can be set on any property (speed and/or frequency

Product Specifications

Operating temperature range

-18C to 55C (0F to 130F) using alkaline

-40C to 85C (-40F to 185F) using lithium **

Optimal battery temperature range (AA)

+10°C to +50°C (+50°F to +122°F

Speed measurement range

0 to 25.5 mm/s

Speed measurement resolution

10 to 200Hz

Frequency measurement resolution

1 Hz

Vibration intensity threshold range

0 to 1.701 g

Vibration intensity threshold resolution

0.063 g

Accelerometer g-Force Range

+/- 2g

Integrated memory

Up to 3200 sensor messages

Security

Encrypt-RF® (256-bit key exchange and AES-128 CTR)

Weight

3.7 ounces

Certifications

900 MHz product; FCC ID: ZTL-G2SC1 and IC: 9794A-G2SC1. 868 and 433 MHz product tested and found to comply with: EN 300 220-2 V3.1.1 (2017-02), EN 300 220-2 V3.1.1 (2017-02) and EN 60950
